ball mill is used in cement,refractories,chemicals,nonferrous and ferrous metals for grinding various ores or other materials. - details see: https://www.machineto.com/high-quality-vibration-mill-ball-supplier-in-china-10314309

Ball Mill Introduction

Vibration ball mill Ball mill Dajia's major product, professional technology support and all-around service can be offered to you, we also can made according to your special requirments. Welcome you visit our company to know more about us!

Ball Mill Application

Vibration Ball mill are generally used to grind material 1/4 inch and finer, down to the particle size of 20 to 75 microns. To achieve a reasonable efficiency with ball mills, they must be operated in a closed system, with oversize material continuously being recirculated back into the mill to be reduced. Various classifiers, such as screens, spiral classifiers, cyclones and air classifiers are used for classifying the discharge from ball mills. VibrationBall mill is an efficient tool for grinding many materials into fine powder.

The Vibrationball mill is used to grind many kinds of mine and other materials, or to select the mine. It is widely used in building material, chemical industry, etc. There are two ways of grinding: the dry process and the wet process. It can be divided into tabular type and flowing type according to different forms of discharging material.

Product Show

Ball Mill Working Principle Intermittent

Vibrationball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber.

The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.

Certification and Honors

Specification of Ball Mill

Model	Speed of bucket	Weight	Size of	size of outputting	Production	Power	Weight
	(r/min)	of ball	feed opening(mm)	feed (mm)	(t/h)	(kw)	(T)
900*1800	38	1.5	<20	0.075-0.89	0.65-2	18.5	3.6
900*3000	38	2.7	<20	0.075-0.89	1.1-3.5	22	4.6
1200*2400	32	3.8	<25	0.075-0.6	1.5-4.8	45	12.5
1200*3000	32	5	<25	0.075-0.4	1.6-5	45	12.8
1200*4500	32	7	<25	0.075-0.4	1.6-5.8	55	13.8
1500*3000	27	8	<25	0.075-0.4	2-5	90	17
1500*4500	27	14	<25	0.075-0.4	2-5	110	21
1500*5700	27	15	<25	0.075-0.4	3.5-6	132	24.7
1830*3000	24	11	<25	0.075-0.4	2-5	180	28
1830*6400	24	23	<25	0.075-0.4	6.5-15	210	34
1830*7000	24	25	<25	0.075-0.4	7.5-17	245	36
2200*5500	21	30	<25	0.075-0.4	10-22	370	48.5
2200*6500	21	30	<25	0.075-0.4	14-26	280	52.8
2200*7500	21	33	<25	0.075-0.4	16-29	475	56
