ceramic glaze ball mill machine

ceramic glaze ball mill machine, 1.Both dry and wet grinding types available, 2.ISO:9000, 3.35% - details see: https://www.machineto.com/ceramic-glaze-ball-mill-machine-10314018

color:green

used:ceramic glaze ball mill machine

ceramic glaze ball mill machine

1.The ball mill is a key piece of equipment for grinding crushed materials, and it is widely used in production lines for powders such as including cement, silicates, refractory material, fertilizer, glass ceramics, etc. as well as for ore dressing of both ferrous non-ferrous metals. The ball mill can also be used for the dry and wet grinding for all kinds of ores and other grind-able materials.

2.Main technical parameters:

Model	Cylinder rotary speed(r/min)	Loading ball weight(t)	Feed size(mm)	Discharge size(mm)	Capacity(t/h)	Motor power(kw)	Weight(t)
Ø900×1800	36-38	1.5	≤20	0.075-0.89	0.65-2	18.5	4.6
Ø900×3000	36	2.7	≤20	0.075-0.89	1.1-8.5	22	5.6
Ø1200×2400	36	3	≤25	0.075-0.6	1.5-4.8	30	12
Ø1200×3000	36	3.5	≤25	0.074-0.4	1.6-5	37	12.8
Ø1200×4500	32.4	5	≤25	0.074-0.4	1.6-5.8	55	13.8
Ø1500×3000	29.7	7.5	≤25	0.074-0.4	2-5	75	15.6
Ø1500×4500	27	11	≤25	0.074-0.4	3-6	90	21
Ø1500×5700	28	12	≤25	0.074-0.4	3.5-6	130	24.7
Ø1830×3000	25.4	11	≤25	0.074-0.4	4-10	130	28
Ø1830×4500	25.4	15	≤25	0.074-0.4	4.5-12	155	32
Ø1830×6400	24.1	21	≤25	0.074-0.4	6.5-15	210	34
Ø1830×7000	24.1	23	≤25	0.074-0.4	7.5-17	245	36
Ø2100×3000	23.7	15	≤25	0.074-0.4	6.5-36	210	34
Ø2100×4500	23.7	24	≤25	0.074-0.4	8-43	245	42
