grinding ball mill

Ball Mill/Tube Mill/Grinder Mill is the key equipment for grinding after the crush process, it is widely used in cement ,silica - details see: https://www.machineto.com/grinding-ball-mill-10314016

Condition:New

Type:Ball Mill

Place of Origin:Jiangsu China (Mainland)

Brand Name:right

Ball Mill/ grinding mill/crusher is an efficient tool for grinding many materials into fine powder. The ball mill is used to grind many kinds of mine and other materials, or to selectthe mine. It is widely used in building material, chemical industry, etc. Thereare two ways of grinding: the dry process and the wet process. It can be dividedinto tabular type and flowing type according to different forms of discharging material.
Technical Data:

Specification(mm)	Production Capacity(t/h)	Effective Volume(t/h)	Power(kw)	Remarks.	Effective Size(mm)
Ø900×3200	0.6-0.8	2	30	steel liner	<25
Ø1200×4500	1.8-2.2	4.43	55	steel liner	<25
Ø1500×5700	4.5-5.0	8.75	130	steel liner	<25
Ø1830×6400	7.0-9.0	14.76	210	steel liner dry	<25
Ø1830×6400	7.0-9.0	14.76	210	rubber liner wet	<25
Ø1830×7000	7.0-12.5	16.44	245	steel liner dry	<25
Ø2200×6500	14-15	21.3	380	steel liner with 380V motor	<25
Ø2200×6500	14-15	21.3	380	steel liner with 600V motor	<25
Ø2200×7000	15-16	23.1	380	steel liner with 380 motor	<25
Ø2200×7000	15-16	23.1	380	steel liner with 6000V motor	<25
Ø2200×7000	15-16	23.1	380	ruber liner with 10000V motor	<25
Ø2400×8000	18-10/16-17	32.2	475	steel liner with 6000V motor	<25
Ø2400×10000	18-22/17-19	40.3	630	ZD80 with 10000V motor	<20
Ø2400×12000	25-27/20-23	46.5	800	MBY630 with 10000V motor	<25
Ø2600×13000	30-32/26-28	60.5	1000	MBY710 with 10000V motor	<25
Ø3000×9000	35-40/28-32	58.5	1000	MBY710 with 10000V motor	<25
Ø3000×11000	40-44/33-35	71	1250	MBY800 with 10000V motor	<20
Ø3000×12000	43-46/36-38	73.9	1400	MBY800 with 10000V motor	<20
Ø3000×13000	45-48/38-40	76.8	1400	MBT900 with 10000V motor	<20
Ø3200×13000	50-53/42-44	88.95	1600	MBT1100 with 10000V motor	<20
Ø3800×13000	65-75	133.86	2000	JS130-C-F1 with 10000V motor	<25
