rod mill for iron ore,copper,quartz,stone,cement,building material ,ferrous of henan,china

Rod Mill, 1.Capacity:0.65-29t/h, 2.Max input size:25mm, 3.Motor power:18.5-475kw, 4.Speed of barrel:21-38r/m - details see: https://www.machineto.com/rod-mill-for-iron-ore-copper-quartz-stone-cement-building-material-ferrous-of-henan-china-10314316

Condition:New	Type:Ball Mill,rod mill	Motor Type:AC Motor	Power(W):18.5-475kw
Capacity(t/h):0.4-29t/h	Place of Origin:China (Mainland)	Brand Name:HMJ	Model Number:various
Dimension(LWH):various	Weight:1.5-33t	Certification:ISO,CE	Warranty:1 year
Application:iron ore,copper,quartz,stone,cement,building material ,ferrous	Griinding way:Wet or Dry	Output Size:0.074-0.6mm/0.074-0.4mm	Max feed size:25mm
Capacity:0.4-29t/h	Motor power:18.5-475kw	Certificate:ISO,CE

rod mill for iron ore,copper,quartz,stone,cement,building material ,ferrous of henan,china

rod mill for iron ore,copper,quartz,stone,cement,building material ,ferrous from henan,China

Rod Mill

1.Rod-mill sand-making machine is widely applicable for wet fine

Using rods to grind materials, the rod mill is a kind of tumbling mill that grinds ores, coal/coke, and other materials in both wet and dry applications.
Rod mill can be used to grind materials that are too wet for fine crushing and dry screening. It also has strong ability to dry grind damp materials that will plug other grinding equipment.

The rod mill can work efficiently to grind products that have a top size of 4 mesh to 16 mesh in an open circuit and 35 mesh in a closed circuit with a screen.
Although better performance is obtained by restricting ore feed size to 3/4", the rod mill accepts feed ore as coarse as 1 1/2" top size.
The correct selection of liners for specific grinding duty helps to reduce scrap loss. More efficiency is achieved by using backing material such as rubber between the liners and the mill shell.

As a specialized rod mill manufacturer in China, Henan Hongji produces many kinds of sand making equipment such as sand making machine, vibrating feeder, belt conveyor, vibrating screen, and sand washing machine, etc.
These products have passed ISO9001:2000 quality system certification and SGS certification. They are sold to Vietnam, Bengal, Myanmar, Laos, Peru, Philippines, Iran, India and other countries.
We believe that you can get your desired sand making equipment from us. We look forward to cooperating with you.

1 - barrel; 2 - end cover; 3 - drive gear; 4 - main bearing; 5 - cylinder liner plate; 6 - end cover plate; 7 - to pocket; 8 - feeding mouth; 9 - row ore mouth; 10 - flange; 11 - access port

2.crushing and coarse crushing

3.Safe operation

Specification of Rod Mill:

Rod_mill san_making machine is one of important equipment in sandstone industry and is mainly used for processing

and crushing such ore and raw materials as feldspar, quartz and scree, etc.

The cylinder revolves in certain speed, the grinding medium goes up to certain height and falls down,

so the materials are stroke and grinded, and the aim of sand making is realized.

Application of Rod Mill:

Rod-mill sand-making machine is widely applicable for crushing all kinds of ores and rocks in metal, non-metal, water conservancy and construction materials industry.

type	speed of barrel(r/min)	ball weight(t)	input size(mm)	output size(mm)	capacity(t/h)	power(kw)	weight(t)
φ900×180	38	1.5	≤20	0.075-0.89	0.65-2	18.9	3.6
φ900×3000	38	2.7	≤20	0.075-0.89	1.1-3.5	22	4.6
φ1200×2400	32	3.8	≤25	0.075-0.6	1.5-4.8	45	12.5
φ1200×3000	32	5	≤25	0.075-0.4	1.6-5	45	12.8
φ1200×4500	32	7	≤25	0.075-0.4	1.6-5.8	55	13.8
φ1500×3000	27	8	≤25	0.075-0.4	2-5	90	17
φ1500×4500	27	14	≤25	0.075-0.4	3-6	110	21
φ1500×5700	27	15	≤25	0.075-0.4	3.5-6	132	24.7
φ1830×3000	24	11	≤25	0.075-0.4	4-10	180	28
φ1830×6400	24	23	≤25	0.075-0.4	6.5-15	210	34
φ1830×7000	24	25	≤25	0.075-0.4	7.5-17	245	36
φ2200×5500	21	30	≤25	0.075-0.4	10-22	370	48.5
φ2200×6500	21	30	≤25	0.075-0.4	14-26	380	52.8
φ2200×7500	21	33	≤25	0.075-0.4	16-29	475	56
