2200*5500 ball mill for sale

Type:ball mill, capacity:10-14, Reliable quality assurance, simple structure high capacity, best servce - details see: https://www.machineto.com/2200-5500-ball-mill-for-sale-10313883

Condition:New	Type:Ball Mill	Motor Type:AC Motor	Power(W):18.5-800
Capacity(t/h):10-14	Place of Origin:Henan China (Mainland)	Brand Name:Jinlong	Model Number:2200*5500
Weight:63	Certification:CE,ISO	Warranty:1-2 years	After-sales Service Provided:Overseas service center available
item:ball mill	Weight of ball(t):30

contact supplier for 2200*5500 ball mill for sale

Application of Ball Mill:

Ball mill is a new developed mill by our company, introducing the first class industrial technique and absorbing the former experience of our company. Through dry or wet way, it is widely used in grinding cement production, carbonate, new type construction materials, fireproof stuff, etc.

Working Principle of Ball Mill:

The ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.

Specification:

High efficiency
Convenient maintenance
Stable performance

Technical parameter
Model	Speed of Bucket(r/min)	Weight of Ball(t)	Size of Feed Opening(mm)	Size of Output(mm)	Capacity (t/h)	Power (kw)	Weight(t)
Φ900×1800	38	1.5	≤20	0.075-0.89	0.65-2	18.5	3.6
Φ900×3000	38	2.7	≤20	0.075-0.89	1.1-3.5	22	4.6
Φ1200×2400	32	3.8	≤25	0.075-0.6	1.5-4.8	45	12.5
Φ1200×3000	32	5	≤25	0.075-0.4	1.6-5	45	12.8
Φ1200×4500	32	7	≤25	0.075-0.4	1.4-2	45	13.8
Φ1500×3000	27	8	≤25	0.075-0.4	2-5	90	17
Φ1500×4500	27	14	≤25	0.075-0.4	2.5-4	110	21
Φ1500×5700	27	15	≤25	0.075-0.4	3.5-4.5	135	24.7
Φ1830×3000	24	11	≤25	0.075-0.4	4-10	180	28
Φ1830×6400	24	23	≤25	0.075-0.4	5.5-6.4	210	34
Φ1830×7000	24	25	≤25	0.075-0.4	6-7	245	36
Φ2200×5500	21	30	≤25	0.075-0.4	10-14	370	48.5
Φ2200×6500	21	30	≤25	0.075-0.4	14-15	380	52.8
Φ2200×7500	21	33	≤25	0.075-0.4	16-22	475	56
Φ2400×1300	19.17	65	≤25	0.075-0.4	28-35	560	137.6
Φ2600×1300	19.5	78	≤25	0.075-0.4	33-50	630	140
