Long service life ball mill---ZHAOXIN ball mill manufacturers

ball mill manufacturers:, 1:low energy consuming, 2:ISO certificated, 3:exported to more than 30countries, 4:focus on quality - details see: https://www.machineto.com/long-service-life-ball-mill-zhaoxin-ball-mill-manufacturers-10314245

Condition:New	Type:Ball Mill	Motor Type:AC Motor	Power(W):11000-1250000
Capacity(t/h):0.3-276	Place of Origin:Shandong China (Mainland)	Brand Name:zhaoxin	Model Number:MQG
Dimension(LWH):384318501400mm-1900077506326mm	Weight:4210kg-154000kg	Certification:ISO9001:2008	Warranty:one year (except wearing parts)
After-sales Service Provided:Engineers available to service machinery overseas	Revolution of the shell:17.5-41.6r/min	Out put:0.3-276t/h	Weight with balls:1.1-102t
Size of supplying minerals:25mm

ZHAOXIN ball mill manufacturers

CERTIFICATED

Ball mill mining machinery features:

1: Large diameter double row self-aligning roller bearings are adopted for main bearing instead of the original sliding bearing.

2: Reducing the friction and energy consumption ,and making the mill start up easily.

3: It maintains the end cover structure of common mill ,with large-caliber feeding and discharging opening,which realizes large processing capacity.

4: It have the advantages like low price ,low energy consuming ,easy operation and installation ,convenient maintenance.

Technical parameters:

Model	Standards	Revolution of the shell (r/min)	Weight with balls (t)	Size of supplying minerals (mm)	Output (t/h)	Cooperate Motor
Model	Standards	Revolution of the shell (r/min)	Weight with balls (t)	Size of supplying minerals (mm)	Output (t/h)	Model	Power (kw)
MQG0912	φ900×1200	41.6	1.1	25	0.3-0.9	Y180L-8	11
MQG0921	φ900×2100	41.6	1.8	25	0.6-1.5	Y180L-6	15
MQG1224	φ1200×2400	35.1	4.0	25	1.6-4.1	Y280S-8	37
MQG1228	φ1200×2800	35.1	4.6	25	1.9-4.8	Y280M-8	45
MQG1232	φ1200×3200	35.1	5.3	25	2.2-5.5	Y280M-8	45
MQG1244	φ1200×4400	35.1	7.3	25	3.0-7.5	Y135S-8	55
MQG1324	φ1300*2400	30.2	4.5	25	1.5-3.5	Y280S-8	37
MQG1328	φ1300*2800	30.2	5.2	25	2.0-4.5	Y280M-8	45
MQG1524	φ1500*2400	30.7	7.0	25	2.8-6.5	YR280S-8	55
MQG1557	φ1500*5700	30.7	17.0	25	7.0-15.5	JR128-8	130
MQG1870	φ1830*7000	25.04	27.3	25	8.5-45.0	JR138-8	320
MQG2160	φ2100*6000	23.8	28.5	25	5.8-40.5	JR138-8	380
MQG2727	φ2700*2700	21.7	24	25	7-78	JR138-8	280
MQG3245	φ3200*4500	18.7	65	25	100-145	TDMK600-36	630
MQG3660	φ3600*6000	17.5	102	25	184-276	TM11250-40/3250	1250

♥ We have all kinds of ball mill machine , welcome to contact me .

Product Quality pass ---- ball mill mining machine

Professional Ball mill and mining machine manufacturers:

Ball mill's parts:

Workshop:

Shandong (Zhaoxin) Mining Machine Group Companyis ISO9001-2008 certificated. With30 yearsmanufacturing experience and scientific management and strong financial strength ,the company has become a large and leading manufacturer in mineral processing and smelting equipment for nonferrous metals and nonmetals in Shandong area .Zhaoxin machinery has exported to20 and more countries.The company mainly manufactures mineral processing and smelting equipment with daily processing capacity of50 to 5000 MTand automatic cotrol equipment with20 varieties and more than 200 items. Among processing equipment , there includes feeding , crushing , sieving , grinding , classification , stirring ,flotation ,magnetic separation and cold separation . Moreover , the company offers full service from mining , prospecting , mineral processing experiment , project technical design , machinery and equipment installing to technical conduction and operators training .
