Hongxing Energy Saving MBS Type Rod Mill

MBS Type Rod Mill, 1 even output granularity, 2 reasonable structure, 3 wide application, 4 high productivity - details see: https://www.machineto.com/hongxing-energy-saving-mbs-type-rod-mill-10313924

Condition:New	Type:Rod mill	Motor Type:AC Motor	Power(W):.
Capacity(t/h):0.62--180t/h	Place of Origin:Henan China (Mainland)	Brand Name:Hongxing	Model Number:MBS
Dimension(LWH):.	Weight:.	Certification:ISO9001--2008,CE	Warranty:1 Year,1 year
After-sales Service Provided:Engineers available to service machinery overseas	Name:Hongxing Energy Saving MBS Type Rod Mill	Application:Ore,cement,construction,railway	Structure:Reasonable
Installation:Engineer guide	Color:Orange

Types of Hongxing Energy Saving MBS Type Rod Mill

MBS type rod mill has dry and wet two types to choose, users could choose depending on the actual needs.

Structure of Hongxing Energy Saving MBS Type Rod Mill

Depending on the reduction box and the reduction of the peripheral big gear wheel, the motor rotary drives the cylinder rotating or the motor drives the cylinder rotating directly by the peripheral big gear wheel. And inside the cylinder, there’s an appropriately grinding medium-steel bar .The steel bar will drop after reaching a certain height with friction and the centrifugal force. And the material will be hit and grinded to achieve the purpose of making sand.

Description of Hongxing Energy Saving MBS Type Rod Mill :

Our company uses the advanced controllable feeding and discharging technology and combines the suitable grinding body according to the actual milling materials. It changes the traditional surface contact into line contact. Then it produces more even output granularity and higher productivity. It is widely used in industries of high evenness requirement, such as: refractory material, chemical industry, metallurgy, glass, etc. In recent years, it is also used in building sand making industry.

Model	Shell Specifications (mm)		Shell rotation speed (r/min)	Feeding size (mm)	Discharging size (mm)	Processing capacity (t/h)	Power (kw)	Total weight (kg)
Model	Diameter	Length	Shell rotation speed (r/min)	Feeding size (mm)	Discharging size (mm)	Processing capacity (t/h)	Power (kw)	Total weight (kg)
MBS0918	900	1800	36-38	≤25	0.833-0.147	0.62-3.2	18.5	5500
MBS0924	900	2400	36	≤25	0.833-0.147	0.81-4.3	22	6100
MBS1224	1200	2400	36	≤25	0.833-0.147	1.1-4.9	30	12000
MBS1530	1500	3000	29.7	≤25	0.833-0.147	2.4-7.5	75	16800
MBS1830	1830	3000	25.4	≤25	0.833-0.147	4.8-11.6	130	29000
MBS2130	2100	3000	23.7	≤25	0.833-0.147	14-35	155	34800
MBS2136	2100	3600	23.7	≤25	0.833-0.147	19-43	180	37000
MBS2430	2400	3000	21	≤50	0.833-0.147	25-65	245	54000
MBS2736	2700	3600	20.7	≤50	0.833-0.147	32-86	380	86000
MBS2740	2700	4000	20.7	≤50	0.833-0.147	32-92	400	94000
MBS3245	3200	4500	18	≤50	0.833-0.147	64-180	630	137000
