1, using ultrasonic welding, 2, PCL systerm control, 3, the high stabilty, the lower failure, 4,with aluminum alloy rack - details see: https://www.machineto.com/high-quality-non-woven-boot-machine-10267195

High Quality Non-woven Boot Machine

.Performance Characteristics

ALT-420 Foot Cover Machine adopt advanced ultrasonic welding to non-woven Foot Cover forming a fold. It is a fully automatic production machine from raw material supplying to finished product output. With PLC system control, the stability is high, the failure is low. Import deceleration brake motor effectively reduced the defect rate of products. This machine with aluminum alloy rack, the appearance is beautiful and will not get rusted permanently. Under replacing the mould it can produce the different specification foot cover

Main Technical Parameters

Type: ALT-420

Power supply voltage: AC380V or 220V

Power: 6.5KW

Design speed: 100pcs / min

Optimum speed :50-80 pcs/ min

Dimensions: 6800 * 1380 * 1600mm

Weight: 2000kg

Choosing us

1. We have passed ISO9001 Quality System Attestation .

2. We have professional technicians for the perfect equipment.

3. We can avouch for the quality with the strict QC system.

4. Wherever you need testing or training, we have the best after-sale service.

After-sale service

1. We will arrange professional technician for installing machinery in your site.

2. We can train your operators if you need
