Cement Mill--China No.1

+2000 case plants in China., Stable, smooth and reliable performance., Highest quality with affordable price, Higher Capacity - details see: https://www.machineto.com/cement-mill-china-no-1-10314815
Condition:NewType:Raymond MillMotor Type:AC MotorPower(W):87KW--670KW
Capacity(t/h):1-40T/HPlace of Origin:Guangxi China (Mainland)Brand Name:HongchengModel Number:HC
Weight:5-132TCertification:ISO CEAfter-sales Service Provided:Engineers available to service machinery overseasApplication:Mineral Powder Processing
Cement Mill--China No.1
contact supplier for Cement Mill--China No.1


Raymond Mill/Grinding Mill/Ultrafine Mill---China No.1 +2000 Case Plants in China

Application of Cement Mill --China No.1:

Also choice for nonflammable and non-explosive minerals of which Moh’s hardness is less than 9.3, moisture content is less than 6%, for example: quartz, feldspar, calcite, talcum, barite, fluorite, Rare earth, marble, ceramic, aluminous bauxite, manganese ore, iron ore, copper ore, phosphorus rock, red ferric oxide, Zircon, slag, granulating slag, cement clinker, active carbon, dolomite, granite, garnet, yellow ferric oxide, fertilizer, multiplex fertilizer, fly ash, soft coal, coking coal, lignite, magnesite, chromium oxide green, gold ore, red clay, clay, kaolin, coal tar creosote, coal slack, porcelain clay, cyanite, fluorspar, bentonite clay, medical stone, rhyolite, greenstone pyrophillite, shale, basalt, gypsum, graphite.

Working Principles of Cement Mill --China No.1:

Firstly, raw material is crushed by jaw crusher to the required size, which is lifted up to the hopper. Secondly, the raw material goes into the grinding chamber through the electro-magnetic vibrating feeder at an even rate. Thirdly, the raw material lifted by the shovel is ground into powder between the ring and roller. Fourthly, the powder is blown up to the cyclone collector through the classifier, which will be collected through the discharging valve. The unneeded powder, which cannot go through the classifier, will be reground into the needed powder.

Advantages of Cement Mill --China No.1 :

1) The only professional producer of Raymond Mill in China.

2) Power-saving and Higher Production Capacity (1-40T/H)

3) Smooth and Reliable Performance.

4) Fineness: 100—800 Mesh (Adjustable)

5) Run for 1000 hours without Lubrication

Technical Data of Cement Mill --China No.1 :

Model

2R27133R32204R3216/32185R4119/4121

Roller

No. of Roller2345
Diameter: (mm)270320320410
Height: (mm)130200160/180190/210

Ring

Inner Diameter:

(mm)

780970970127 0
Height: (mm)130200160190

Max. Feeding Size (mm)

≤15≤20≤20≤25

Fineness(mm)

0.044-0.1250.044-0.1250.044-0.1250.044-0.125

Total Power (kw)

42.587.587.5172.5

Capacity: (t/h)

0.3-31-4.51-4.52-9

Overall Dimension

(L×W×H)(mm)

5490×3875×55307464×5000×83457464×5000×834511345×6885×10330

Weight: (t)

5.51414.228

Model

HC1000HC1300HC1460HC1700HC2000

Roller

Number of Rollers34455
Diameter(mm)320410460510620
Height(mm)200230250250250

Ring

Inner Diameter(mm)9701270146017002000
Height(mm)200210250250250

Max. Feeding Size(mm)

≤20≤25≤35≤50≤50

Fineness(mm)

0.015-0.180.044-0.180.022-0.180.022-0.180.022-0.18

Total Power(kw)

105183.5/198.5242364670

Capacity(t/h)

1.5-63-125-156-2520-45

Weight(t)

14283746102

The Solution of Cement Mill --China No.1:

Cement Mill--China No.1
Packaging Detail:Nude and Plywood Box
Delivery Detail:30 days after 30% advance payment
