1.hydraulic precise 4-column cutting machine, 2.maximum cutting force:50T, 3.cutting area:1600*800mm - details see: https://www.machineto.com/high-quality-artificial-flower-machine-hydraulic-precise-cutting-machine-10265562

QUZHOU TAIWEI PRECISE MACHINERY CO.,LTD is the professional manufacturer of hydraulic cutting machine with 20 year experience,technology leader ,China's first export brand.

Feature of hydraulic precise 4-column cutting machine:

1.more than 20 years hydraulic cutting machine experience
2.maximum cutting machine force:50T
3.hydraulic cutting machine MOTOR POWER:4kw

4.sponge cutting machine cutting area(mm):1600*800mm

5.four-column cutting tension distance(mm):200

Double oil cylinders,auto balance precise four pillars connecting rod structure,it makes differrent cut place in the same deep. Differential designafter the material drops to cutting dies quickly,the machine would auto-cut slowly,makes it no size error between superstratum and underlayer of workpiece.

When cutting environmentally-friendly materials(PS,EPE,PET,ABS,OPS),uncutting or edge fins would not happen; when cutting food box,there would be not material power on the box.

Cutting force micromatic setting could get autofit cutting force,the degree of balance is very precise,reducing the waste of cutting dies and cutting board a large extent.

Operation with the hands,when put the button one time,there would not happen many continuous cutting,moreover there has emergency stop control,operation is highly safe.

Technique Parameter

Model	Max cutting power	Lift stroke	cutting table	Motor power	Weight
TW-530B	30T	50-200mm	1600*500mm	3Hp	1800kg
TW-540B	40T	50-200mm	1600*600mm	4Hp	2000kg
TW-550B	50T	50-200mm	1600*800mm	4Hp	3000kg
TW-5100B	100T	50-200mm	1600*1100mm	7.3Hp	3600kg
