SUDA MINI CNC ROUTER /CNC ENGAVER/ CNC CUTTER FOR SIGN MAKING-sd3025
small size, CE certifiate, 800w water cooling spindle motor, rolling ball screw from Germany, thk linear rail - details see: https://www.machineto.com/suda-mini-cnc-router-cnc-engaver-cnc-cutter-for-sign-making-sd3025-10367206
| Place of Origin:Anhui China (Mainland) | Brand Name:SUDA | Model Number:SD3025V | spindle power:800w watercooling spindle motor |
| transmitting parts:rolling ball screw from Germany | certificate:CE | | |
| Model | SD3025SV New modle from SHANGHAI EXHIBITION July |
| Table size (cm) | 30*25 |
| X Y Z Guide | Rolling ball screw from Germany,X,Y,Z axis all configured with imported Linear rail,more processing accuracy . |
| XYZ movement (mm) | 300 x 250 x 40 |
| Spindle power | 800W |
| Spindle speed (min/max) | 6000 - 24000 U/Min. |
| Machine dimension (cm) | 56*54*59 |
| Packing dimension (cm) | 66*64*69 |
| Weight (kg) | 95KG |
| Power consumption without spindle | More than 1000w |
| Speed max. | 0-70mm/s |
| Working speed max. | 70mm/s |
| Stepper or servo motor? | Stepping motor |
| XYZ accuracy | 0,04mm |
| Reposition accuracy | 0,01mm |
| XY resolution | 0,025mm |
| Z resolution | 0,025mm |
| Table surface | Aluminum |
| XY drive configuration | roll screws |
| Z drive configuration | roll screws |
| Included Software | Type3 V4.3 english |
| Software Compatible with | Win98/Win2000/XP |
| Spindle coolin system | water cooled |
| Spindle collet | ER11 |
| Software transmission language | G-Code, HPGL |
| Interface | Transimt the file from USB flask disk directly |
| Voltage | 220VAC/50-60Hz |
| Running environment | 0-35°C, humidity: 10-70% |
| Production time | 10 working days when we received all the payment by T/T |
| Packaging Detail:plywood case good for shipping by sea |
| Delivery Detail:8 days after your payment by t/t |
