Seven row auto feeding multiple spindle drilling machine

Seven row auto feeding multiple spindle drilling machine, We supply different function Auto feeding spindle drilling machine. - details see: https://www.machineto.com/seven-row-auto-feeding-multiple-spindle-drilling-machine-10348552
Condition:NewCNC or Not:NormalPlace of Origin:Shandong China (Mainland)Brand Name:MNTools
Model Number:MTBJK152APower(W):14.75kwWeight:2800kgsDimension(L*W*H):4150*1800*1600mm
Certification:ISO9001
Seven row auto feeding multiple spindle drilling machine
contact supplier for Seven row auto feeding multiple spindle drilling machine


Seven row auto feeding spindle drilling machine

Main characteristic:

1. It takes progressive touch screen,PLC control system with Multi-function.

2. High load capacity with special double guide line . mbe agility and duribility.

3. The position fix up system from Germany display ,fix exactly and easy control.

4. Motor direct the driller and can tilt 0~90 ,have different driller mode.

5. Combined high speed Auto feeding with auxiliary feeding work coutinuously

with high effxiency.

6. Serialized products with reliable quality ,can fultil your need .

Model No.MTBJK152A
Distance between the bit32mm
The quantity of boring box
Horizontal2
Vertica5×2=10
The quantity of the bit152
Max panel diameterΦ35mm
Max panel thickness60mm
Max panel width2450mm
Min panel width250mm
Feeding speed57m/min
Power14.75KW 380V 50HZ
Pneumatic power0.6~0.8Mpa
Machine size(L×W×H)mm4150×1800×1600mm
Packing size (mm)4230×1970×1800mm
Net weight2800Kg
Seven row auto feeding multiple spindle drilling machine
Packaging Detail:exporting package
Delivery Detail:30days
