MQ-500 textile waste/fabric cotton waste recycling machinery

Useage :

Our mq-500 model textile waste /fabric cotton waste recycling machineryrecycle kinds of textile waste ( knitting hosiery denim thread yarn , cloth waste and leftover of garment ) get the fiber from these waste enable to use for rotor spinning standard and any other textile purpose like raw cotton, make a good use of textile waste material ,save cost and make benefit . normally use in spinning mills weaving mills garment mills non-woven mills and cotton waste processing mills etc.

technical data

1) QD-350 CUTTING MACHINERY 1 SET (FOR CUTTING OFF THE PCS)

2) MF-1200 FEEDING MACHINE 1 SET (TRANSPORT THE RAW MATERIAL)

3) MQK-700 OPENNER 1 SET (NAIL PINS CYLINDER DIAMETER 700MM OPENNER)

4) MQF-500 RECYCLING MACHINERY 7 SETS (CYLINDER IS CARD CLOTHING DIAMETER IS 530MM)

6) AT-63 200 TON HYDRAULIC BALER AUTOMATIC 1SET 250kgs per bale

QD-350 Cutting Machine->MQK-700 openning machine ->7sets MQ-500 Cotton waste cleaning machine->Baling Machine AT-63

Production of whole line: 500kg/hr

Main Machine General power:185kw

Voltage:380v/50hz

Operator:2-3 person

Advantage of this textile waste recycling line :

1. High production. Normal level production of this kind of producing line is 500KG/HR

2. Adopt special card cloth ,this new technology furthest reduced the damage for the fiber, avoid balling up at the same time.

3. Specially used for the regeneration of all kinds of textile waste (knitting fabric, weaving fabric, etc.) ,all kinds of textile materials ( polyester ,synthetic , or cotton, jute cloth etc.) ,spinning waste( yarn head ,yarn waste, card fly, droppings etc.)

4. .High level automatic whole production line only need two operator.

Working flow introduction:

Step 1: Raw material first be cut into pieces ( length adjustable from 5cm-20cm);

Step 2: the shorten raw material will go through the feeding machine MF-1200(Optional).This model is specially designed for this producing line.

Step 3: After step 2, materials will be sent to MQK-700. Finished products from this machine are cotton mix with some thread. This is one of the most important

Part of this textile waste recycling line, protects the fiber on the greatest level.

Step 4: This part is another important part of the whole line. It is the further process of the product get from step 3. After this step, we will get the cotton nearly same as the raw cotton. It can be reused again in many relating industries.

Step 5: Bale the finished products by hydraulic baling machine. Optional .
