mixing tank

Hangzhou Yintong Machinery Co.,LTD specialized in manufacturing kind of tanks made of stainless steel (SUS304 or SUS316L). - details see: https://www.machineto.com/mixing-tank-10298137
Mixer Type:Planetary MixerApplication:LiquidAdditional Capabilities:GranulatingPlace of Origin:Zhejiang China (Mainland)
Brand Name:YTModel Number:MT_41Material:Stainless steel304/316
mixing tank
contact supplier for mixing tank


The series of SS. Mixing tanks are made of stainless steel (SUS304 or SUS316L). All joints and inside is mirror finished without any dead angle and cleaned easily. It consists of inner vessel, jacket and insulation with the configurations of agitator, CIP hole, Manhole, sight glass, thermometer etc.

1 It is sealed type, and the material contacting the liquid is the stainless steel 304 or 316L

2 One set of totally enclosed blending plant

3 A self-rotating type cleaning

4 A set of air respirator, matching a 0.22μm folding filter element.

5 A set of liquidometer

6 A 0-100 thermometer

7 Manhole 450mm

8 A 100mm sight glass

9 A 036V light

Parameter

LP
300
LP
400
LP
500
LP
600
LP
1000
LP
2000
LP
3000
LP
5000
LP
10000

Cubage(L)

300400500600100020003000500010000

Pressure

Internal bladder

≤ 0.2Mpa

Insert set

≤ 0.3Mpa

Power Kw

0.550.550.750.751.11.51.52.23

Speed of impeller

18=200r/min

Outlook size

Diameter90010001150115014001580180020502500
Height220022202400250027003300360042005000

Heat transfer area

22.42.73.14.57.58.610.420.2

We can also manufacture the tanks according to your special specification.

mixing tank
Packaging Detail:standard package
Delivery Detail:25days after 30% payment
