Mining grinding ball mill for ore, cement clinker, gypsum, glass, ceramic, etc.

1.can design and manufacture at customer's special need., 2.Mining grinding ball mill for ore, cement clinker, gypsum, glass, - details see: https://www.machineto.com/mining-grinding-ball-mill-for-ore-cement-clinker-gypsum-glass-ceramic-etc-10314355

Condition:New	Type:Ball Mill	Motor Type:ANY	Power(W):155kw
Capacity(t/h):0.5-260	Place of Origin:Shanghai China (Mainland)	Brand Name:Shanghai Minggong	Model Number:All
Dimension(LWH):ANY	Certification:CE ISO9001:2000	Warranty:1 YEAR	After-sales Service Provided:Overseas service center available
Model:All Model	Cylinder rotary speed (r/min):39-17	Loading ball weight (t):1.5-144	Input size (mm):≤25
Discharge size (mm):0.074-0.4	Capacity (t/h):0.5-260	Motor power (kw):18.5-1800	Weight (t):4.5-260
keywords:Mining grinding ball mill for ore, cement clinker, gypsum, glass,

Ball Mill

Our company mainly produces two kinds of ball mills, energy-saving ball mill and dry type ball mill. Mining grinding ball mill for ore, cement clinker, gypsum, glass, etc.

Working principle:
Ball mill is an efficient machine for fine powder grinding and key equipment for grinding after the crushing process. There are two ways of ball mill grinding: the dry way and the wet way. It is used to grind many kinds of mineral ores and other materials, or to select mine. Ball mill is also widely used in the manufacturing industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics and can be used for the dry and wet grinding for all kinds of ores and other materials.
Structure:
The machine is composed by feeding part, discharging part, rotation part and driving part (reducer, small driving gear, electric motor and electric control).
Feature:
(1). Easy maintenance and operation;
(2). Big crushing ratio, uniform end product size;
(3). Simple structure;
(4). Low operating cost.

Model	Cylinder rotary speed (r/min)	Loading ball weight (t)	Input size (mm)	Discharge size (mm)	Capacity (t/h)	Motor power (kw)	Weight (t)
Ø900×1800	39	1.5	≤20	0.075-0.89	0.8-2	18.5	4.6
Ø900×3000	39	2.7	≤20	0.075-0.89	1-4	22	5.6
Ø1200×3000	36	3.5	≤25	0.074-0.4	1.6-5	37	12.8
Ø1200×4500	32	5	≤25	0.074-0.4	1.6-5.8	55	13.8
Ø1500×3000	27	7.5	≤25	0.074-0.4	2-5	75	15.6
Ø1500×5700	28	12	≤25	0.074-0.4	3.5-6	130	24.7
Ø1830×3000	25	11	≤25	0.074-0.4	4-10	130	28
Ø1830×6400	24	21	≤25	0.074-0.4	7-16	210	34
Ø1830×7000	24	23	≤25	0.074-0.4	8-18	245	36
Ø2100×3600	23	19	≤25	0.074-0.4	10-36	210	46
Ø2200×4500	21	27	≤25	0.074-0.4	12-23	280	48.5
Ø2200×6500	21	35	≤25	0.074-0.4	14-26	380	52.8
Ø2200×7000	21	35	≤25	0.074-0.4	15-28	380	54
Ø2200×7500	21	35	≤25	0.074-0.4	15-30	380	56
Ø2400×4500	21	30	≤25	0.074-0.4	18-45	320	65
Ø2400×8000	20	36	≤25	0.074-0.4	20-48	410	81
Ø2700×3600	21	39	≤25	0.074-0.4	19-75	400	83
Ø2700×4000	20	40	≤25	0.074-0.4	20-78	400	85
Ø2700×4500	20	48	≤25	0.074-0.4	22-85	430	89
Ø3200×4500	18	65	≤25	0.074-0.4	29-140	800	137
Ø3200×5400	18	81.6	≤25	0.074-0.4	30-180	800-1000	146
Ø3600×4500	17	88	≤25	0.074-0.4	35-210	1000	190
Ø3600×6000	17	117	≤25	0.074-0.4	38-240	1250-1500	220
Ø3600×8500	17	144	≤25	0.074-0.4	45-260	1800	260
