Micro Powder Grinding Mill

Micro Powder Grinding Mill, 1.Mainly use for non-metallic mine, 2.Good fineness& high output, 3.Low energy consumption - details see: https://www.machineto.com/micro-powder-grinding-mill-10314666

Condition:New	Type:Other	Motor Type:AC Motor	Power(W):93KW
Capacity(t/h):1-2t/h	Place of Origin:Fujian China (Mainland)	Brand Name:YF	Model Number:YFM-68
Dimension(LWH):9.2m3.1m5.6m	Weight:12T	Certification:ISO9001	Warranty:Six months
After-sales Service Provided:Engineers available to service machinery overseas	Product Name:Grinding mill	color:Green,Yellow	certificate:ISO9001:2008
installation:offer foundation drawing	application:beneficiation, mineral processing	discharge size:3-35um

Strengths

1.This machine is low cost-priced at less than 30% of similar imported machines

2.It has such advantages as good fineness,high output,low energy consumption and low investm-ent.

3. The fineness of the product can be adjusted as requirement of customer.

4.It has perfect system.Convenient to install, no need largescale construction project.It can be uesd as we finish installing.

Type and Technical Data Form

Technical Data/Type	YFM-68
Fineness(u m)	3-35
Output(kg/h)	500-2000
Power(kw)	80-100

Contrast table of Mesh number, Power consumption and Output of products

(take the calcite for example)

Model Mesh D97	YFM-68
Model Mesh D97	Output(kg/h)	Power consumption (kw/t)
600	1500	40
800	1000	60
1250	800	80
1500	600	110
2500	500	130
Remark:	(1) The smashing material of the parameter is calcite. (2) Because the material from different place will be a bit different, the parameter above is just for reference. (3) Mesh number according to national standard, refer to American standard
