Mesh Belt Dryer for Vegetable and Fruit

1-Mesh belt dryer for dehydration vegetable & fruit, 2-Belt drier can reach a good product quality, 3-Easy use for belt dryer - details see: https://www.machineto.com/mesh-belt-dryer-for-vegetable-and-fruit-10037001

Place of Origin:Jiangsu China (Mainland)	Brand Name:Yuzhou	Model Number:DWT	Type:Dryer
Main use::Drying Machine for vegetable and fruit

contact supplier for Mesh Belt Dryer for Vegetable and Fruit

Descriptions

Vegetable dryer can meet to dry different vegetables, such as root, leaf, halm, tuberous root, big granule in batch. Meanwhile it can maintain content of nutrition, color, ect of vegetable in most extent.

The type raw materials are garlic, cushaw, giantarum, white turnip, yam, bamboo shoot, capsicum, onion, apple, when operation, air will be entered into the dryer and heated through heat exchanger, Being adapted scientific a cycle method, the hot air will pass though raw materials to be dried on the bed and carry out uniform heat exchange action of cycle fan, the hot air stream inside each unit of the dryer will carry out hot air cycle, Final air with low temperature high damp will be out, The whole drying process with stably and high effect will be finished.

Technical parameter

type	DWT-1.2-8	DWT-1.2-10	DWT-1.6-8	DWT-1.6-10	DWT-2-8	DWT-2-10
unit number	4	5	4	5	4	5
belt width m	1.2	1.2	1.6	1.6	2	2
drying section length m	8	10	8	10	8	10
thickness of the material to be covered mm	10∼80
temperature	60∼150
steam pressure Mpa	0.2∼0.8
steam consumption kg/h	120∼300	150∼375	150∼375	170∼470	180∼500	225∼600
drying time (h)	0.2∼1.2	0.25∼1.5	0.2∼1.2	0.25∼1.5	0.2∼1.2	0.25∼1.5
drying strength kgH20/h	60∼160	80∼220	75∼220	95∼250	100∼260	120∼300
total power of the blower kw	6.6	8.8	9	12	12	16
total power kw	7.15	9.55	9.55	12.75	12.55	16.75
