leather shoes industry laser machine

CE and FDA imported parts from usa,germany and first -grade scientific techonoly and woderful after-sales service benefit u - details see: https://www.machineto.com/leather-shoes-industry-laser-machine-10265286

Place of Origin:Shandong China (Mainland)

Brand Name:Bodor

Model Number:BCL

usa imported lens:germany ball screws

contact supplier for leather shoes industry laser machine

Main Features

1. X&Y axis with HIWIN high accuracy square rail, perfect performance.
2. Only manufacturer adopts square tube framework machine body 40% higher than simple iron sheet structure, never distortion. Prevents machine from quivering and resonance during long time work.
3. High efficiency tube with stable laser path, life time reaches to 10000 hours.
4. Red cross point offers highest accuracy position.
5. Humanized and modern design makes work happy, safe and easy.
6. Transparent acrylic watching door, easy checking work process.
7. Professional motion control card offers continue fast curve cutting together with shortest path selection. Shorten work time.

Technical Parameter

Model	BCL1006X	BCL1309X	BCL1610XH	BCL1812XH	Option
Working Area	1000*600mm	1300*900mm	1600*1000mm	1800*1200mm	According to Demands
Laser Power	60w/80w/100w/130w//150w
Laser Type	CO2 Sealed Laser Tube , 10.6μm
Cooling Type	Water Cooling
Engraving Speed	0-60000mm/min
Cutting Speed	0-40000mm/min
Laser Output Control	0-100% set by software
Min. Engraving Size	Chinese: 2.0mm2.0mm, English Letter: 1.0mm1.0mm
Highest Scanning Precision	4000DPI
Locating Accuracy	≤+0.01mm
Controlling Software	DSP Control System
Graphic Format Supported	DST PLT BMP DXF DWG AI LAS,etc
Compatible Software	CORELDRAW,PHOTOSHOP, AUTOCAD,TAJIMA,etc.
Color Separation	Yes
Drive System	High-precision 3-phase Stepper Motor
Auxiliary Equipments	Exhaust Fan and Air Exhaust Pipe
Power Supply	AC110V/220V+10%,50HZ/60HZ
Working Environment	Temperature:0-45C,Humidity 5-95%(No Condensate Water)
