hydrogen storage can

hydrogen storage can, This product can absorb and desorb hydrogen at the room temperature and relatively low pressure. - details see: https://www.machineto.com/hydrogen-storage-can-10282752

Condition:New	Place of Origin:Beijing China (Mainland)	Brand Name:Whole Win	Model Number:Series,series
name:hydrogen storage can	material:stainless steel	application:safe hydrogen storage	capacity of hydrogen storage:10 m3 to 100 m3
Usage:Hydrogen

hydrogen storage can

Text

This product can absorb and desorb hydrogen at the room temperature and relatively low pressure, and more than 90% quantity of the hydrogen stored in it can be desorbed at relatively steady pressure in very steady hydrogen gas current. The hydrogen absorbing and desorbing pressure and the desorbing flow of the product depend on the users’ demand. Through the use of the product, the ordinary hydrogen can be purified into the ultra high pure hydrogen of 5 N purity, which indicates that the technology of the product has reached the international advanced level. The specifications of the product are defined with the amount of the desorbing hydrogen in standard state, which is from several liters to several hundreds of cubic meters. The shape of the product is generally cylindrical, and it can be adjusted with the users’ demand.

1.Small Size

Model	HYM-30S	HYM-50S	HYM-100S/A	HYM-300S	HYM-500S	HYM-750S/A	HYM-1000S
Capability of hydrogen storage	≥30 Liter	≥50Liter	≥100 Liter	≥300 Liter	≥500 Liter	≥750 Liter	≥1000 Liter
Measurement for reference (mm)	DIA40×L90	DIA40×L130	DIA46×L210/ DIA57×L200	DIA66×L310	DIA78×L360	DIA87×L450/ DIA107×L430	DIA154×L380
Gross Weight (kg)	≤0.9	≤1.2	≤2.5	≤5	≤8	≤15	≤25
Material of Pot	steel	steel	steel /aluminum alloys	steel	steel	steel /aluminum alloys	steel
Pressure of hydrogen storage	≤3 MPa	≤3 MPa	≤3 MPa	≤3 MPa	≤3 MPa	≤3 MPa	≤3 MPa
Time of hydrogen charging(25°C)	≤30 min	≤50 min	≤60 min	≤70 min	≤90 min	≤150 min	≤160 min
Released speed of hydrogen (25°C)	≥1 L/min	≥1 L/min	≥1 L/min	≥2 L/min	≥3 L/min	≥4 L/min	≥8L/min

2.Large Size

Model	HYM-5M	HYM-10M	HYM-30M	HYM-40M	HYM-50M	HYM-80M
Capability of hydrogen storage	≥5 m3	≥10 m3	≥30 m3	≥40 m3	≥50 m3	≥80 m3
Measurement for reference (mm)	DIA240×L660	DIA280×L950	DIA380×L1400	DIA430×L1400	DIA510×L1250	DIA550×L2100
Gross Weight (kg)	≤75	≤150	≤440	≤620	≤750	≤1000
Material of Pot	steel	steel	steel	steel	steel	steel
Pressure of hydrogen storage	≤3 MPa	≤3 MPa	≤3 MPa	≤3MPa	≤3 MPa	≤3 MPa
Time of hydrogen charging (25°C)	≤60min	≤60min	≤120min	≤120min	≤150min	≤150 min
Released speed of hydrogen (25°C)	≥30 L/min	≥45 L/min	≥110 L/min	≥150 L/min	≥160 L/min	≥200 L/min
