High Efficiency Ball mill Price

Main features for fball mill, 1)Simple&new structure, 2)Easy maintenance and operation, 3)Low operating cost, 4)Big crushing rat - details see: https://www.machineto.com/high-efficiency-ball-mill-price-10314716

Condition:New	Type:Ball Mill,Mill	Capacity(t/h):According to the sizes	Place of Origin:Henan China (Mainland)
Brand Name:Tianrong	Model Number:As requested	Application:Ore	Colour:red ,green,orange
Usage:to smash all kinds of ores and materials	Warranty:12 months	After sales services:for whole using life

contact supplier for High Efficiency Ball mill Price

1. Application of Ball mill

Ball millis the key equipment for fine powder grinding after the crushing process, which is is widely used in powder-making production line, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics . The can grind various ores and other materials with both dry type and wet type.

2. Working Principle of Ball Mill

There are two chambers and grid in the . Materials are put into the first chamber through the feeding inlet. The shell rotates to generate electricity, and this force brings ball to a certain height and then balls drop down by gravity, the impact is the grinding force to the material. After the primary grinding, materials are put into the second chamber through segregate screen. In the second chamber, there are flat liners and steel ball. After the secondary grinding, material is discharged from the outlet port. Then the whole grinding process end.

3. Main Features of Ball Mill

1)Simple structure
2)Easy maintenance and operation
3)Low operating cost
4)Big crushing ratio

4.Specifications of Ball Mill

Model	Rotationna speed(r/min)	Ball load(t)	Feeding size(mm)	Output size(mm)	Capacity	Power(kw)	Weight(t)
Model	Rotationna speed(r/min)	Ball load(t)	Feeding size(mm)	Output size(mm)	(t/h)	Power(kw)	Weight(t)
900×1800	36~38	1.5	≤20	0.075-0.89	0.65-2	18.5	4.6
900×3000	36	2.7	≤20	0.075-0.89	1.1-3.5	22	5.6
1200×2400	36	3	≤25	0.075-0.6	1.5-4.8	30	12
1200×3000	36	3.5	≤25	0.074-0.4	1.6-5	37	12.8
1200×4500	32.4	5	≤25	0.074-0.4	1.6-5.8	55	13.8
1500×3000	29.7	7.5	≤25	0.074-0.4	2-5	75	15.6
1500×4500	27	11	≤25	0.074-0.4	3-6	110	21
1500×5700	28	12	≤25	0.074-0.4	3.5-6	130	24.7
1830×3000	25.4	11	≤25	0.074-0.4	4-10	130	28
1830×4500	25.4	15	≤25	0.074-0.4	4.5-12	155	32
1830×6400	24.1	21	≤25	0.074-0.4	6.5-15	210	34
1830×7000	24.1	23	≤25	0.074-0.4	7.5-17	245	36
2100×3000	23.7	15	≤25	0.074-0.4	6.5-36	155	34
2100×4500	23.7	24	≤25	0.074-0.4	8-43	245	42
2100×7000	23.7	26	≤25	0.074-0.4	8-48	280	50
2200×4500	21.5	27	≤25	0.074-0.4	9-45	280	48.5
2200×6500	21.7	35	≤25	0.074-0.4	14-26	380	52.8
2200×7000	21.7	35	≤25	0.074-0.4	15-28	380	54
2200×7500	21.7	35	≤25	0.074-0.4	15-30	380	56
2400×3000	21	23	≤25	0.074-0.4	7-50	245	54
2400×4500	21	30	≤25	0.074-0.4	8.5-60	320	65
2700×4000	20.7	40	≤25	0.074-0.4	12-80	400	94
2700×4500	20.7	48	≤25	0.074-0.4	12-90	430	102
3200×4500	18	65	≤25	0.074-0.4	According to technology	800	137
