1.suitable for Chemical and pharmacy,Food industry such as corn steep liquor, 2.less power consumption., 3. large capacity. - details see: https://www.machineto.com/glucose-evaporator-10047208

JMZ multiple effects falling film evaporator

--energy saving product, break through of zero live steam consumption for evaporation

applications

Chemical and pharmacy such as alcohol and medicine liquor.

2. Food industry such as milk product, high protein, fruit juice, vegetable juice, starch products, sugar, extract and

hydrolyte etc.

product usage

1. JMZ multiple effects falling film evaporator is suitable for evaporating the heat sensitive, high density, high

viscosity and corrosive materials.

2. JMZ multiple effects falling film evaporator can deal with large amount of evaporation.

design principle

model choosing.

1. As per the concentrated material and customer requirements, the evaporation system can be single effect,

2 effects, three effects, four effects, five effects and six effects vacuum evaporation system.

2. JMZ multiple effects falling film evaporator can be running with forced evaporator and crystallizer.

specification and model

specification (JMZ)	210.0	3.0	6.0	12.0	20.0	30.0	50.0	60.0	70.0	80.0	100.0
evaporation (t/h)	210.0	3.0	6.0	12.0	20.0	30.0	50.0	60.0	70.0	80.0	100.0
live steam consumption (t/h)	9.5 (using waste heat)	0.9	1.8	3.6	6.0	9.0	15.0	18.0	21.0	24.0	30.0
steam pressure(MPa)	0.7 (absolute pressure)	0.85(absolute pressure)
inlet DS (%)	4~5 (alcohol mash)	6~7( for CSL)
outlet DS (%)	30~35 (alcohol mash)	42~48(for CSL)

product advantages

1. High heat transfer efficiency, little temperature difference, no boiling lost by fluid column, less power consumption.

2. Big concentration factor(1/5~1/10), large scale of viscosity(<400cp), large capacity, short heating period, and it takes small working place with continually manufacture.

3. Energy saving product, waste heat evaporating unit can use low quality waste heat, afterheat, instead of using

the live steam with their work done.

preferential policy

This is energy-saving and environment protection product. Our company can technically support you to applicate the energy-saving government-funded compensation funds.

product honor

1. 1999

In 1999, grand developed our first waste heat evaporator.

2. 2010

In 2010, evaporation unit using turbo compressor was evaluated as the first heavy equipment and important

component in Jiangsu province by Jiangsu committee on economic and scientific information.

3. 2009In 2009, grand got the certificate of manufacture of A2 pressure vessel

4. In 2007, grand got the ASME ‘U’stamp certificate.

5. In 2006, grand got the certificate of manufacture of D1,D2 pressure vessel

6. JMZ multiple effects falling film evaporator is defined as high-tech products in province

7. The develop of JMZ multiple effects falling film evaporator is state Torch Program.

8. JMZ multiple effects falling film evaporator went through the evaluation by Jiangsu province Science Research

Council
