Full automatic crimped wire mesh weave machine (21 years factory)

Full automatic crimped wire mesh weave machine, 1. weaving width: 1300 or 1600 mm, 2.mesh:40-500mesh, 3.Wire dia:0.04-3.0mm - details see: http://www.machineto.com/full-automatic-crimped-wire-mesh-weave-machine-21-years-factory-10279179
Place of Origin:Hebei China (Mainland)Brand Name:MTModel Number:APMweaving width:1300 or 1600mm
Full automatic crimped wire mesh weave machine (21 years factory)
contact supplier for Full automatic crimped wire mesh weave machine (21 years factory)


Shuttleless wire weaving machine , Woven label weaving machine

1.Application: used for industrial purpose, window doors and poultry’s guards, Sieves, filters and other purpose.

2.Character: single electromotor driving; be suitable for soft metal, stainless steel, flexible copper wire, galvanized wire, etc

(1).The machine adopts technique of shuttleless and straightaway weft leading, automatic warp feeding and winding. Shedding are small and surfaces of woven screens are smooth. There is not any bright spot, bright trace and other defects on fine screen. The machine can make light-grade in the standard of GB/T5330-2003.

(2). Lower center of the gravity, good stability, low noise and energy consumption, high efficiency.

(3). Rational design, simple construction, easy to operate and maintain.

3.Specifications for your reference:

ItemWeaving Width (mm)Wire Diameter

(mm)

Mesh

Size

(mm)

Weave TypeWeight

(KG)

Outsize

(mm)

LZWJ-1300B13000.04-0.2540-400Plain and Twill28002600x2800x1200
LZWJ-1600Q16000.04-0.2540-400Plain and Twill32002630x3200x1360
HZWJ-1300B13000.1-0.8 or

0.03-0.3

10-100 or

40-350

Plain and Twill61552569x3535x1849
HZWJ-1600Q16000.15-0.810-40Plain28002569x3535x1849

4.Pictures for your reference:

The auxiliary machine

spool coiling machine

products made by this machine:

Packaging Detail:directly in the container or as per customers' request
Delivery Detail:1 sets about 20 days
