fertilizer grinding mill, vibration grinding mill
Condition:New | Type:Raymond Mill,Mill | Capacity(t/h):0.5-20TPH | Place of Origin:Shanghai China (Mainland) |
Brand Name:zenith | Model Number:MTM | Application:Ore |
fertilizer grinding mill, vibration grinding mill
Grinding stone Plant is made of jaw crusher, bucket elevator,electrovibrating feeder, main unit, optional equipment, blower,centrally electric control system, etc. According to customersspecific requirement, we can choose high pressure suspension grindingmill or MTM medium speed trapezium mill. This is common-used fertilizer grinding mill .
The Raymond mill is used as coconut shell powder machine . It is a new mill of high efficiency and low consumption, studied by numbers of our engineers, for solving the difficulty of high energy consumption in mill industry. The fertilizer grinding mill ,MTM mill adopts new grinding principle, new structure, strong bearing materials, and absorbing lots of technical essence of mill. Therefore the performance of our mill indicators are over traditional mills greatly.
Especially, barite grinding mill is very efficient for crushing high hardness and hardworking materials and Raymond mill can work under both dry and wet condition.
Our grinding stone machine has these characteristics: small metal worn, little dust, simple and firm structure, and easy maintenance. The fertilizer grinding mill is a revolutionary technical changing in mill industry. The Raymond mill can bring higher economic benefit to our customers and The coconut shell powder machine really fulfills the desire of industrial fields --- high efficiency and low consumption. It is invented for powder making in the new time.
fertilizer grinding mill Specifications:
Item | MTM100 | MTM130 | MTM160 |
Number of roller | 4 | 5 | 6 |
Maximum diameter of roller ×Height (mm) | Φ320×200 | Φ400×240 | Φ440×270 |
Ring inner diameter × Height (mm) | Φ980×200 | Φ1280×210 | Φ1600×270 |
Main engine spindle speed (r/min) | 130 | 103 | 82 |
Maximum feeding grain size (mm) | <25 | <30 | <35 |
Grain size of finished product (mm) | 1.6 -0.038 | 1.6 -0.038 | 1.6 -0.038 |
Output (t/h) | 3-8.8 | 6-13 | 13-22 |
Overall dimension (mm) | 7300×7160×8310 | 8800×7500×9700 | 12550×5700×8355 |
Weight (t) | 16 | 26.1 | 38 |
Name | Item | Unit | Specification and technical data | |||
MTM100 | MTM130 | MTM160 | ||||
Motor of main unit | Model | - | Y225S-4 | Y280S-4 | Y135M1-4 | |
Power | kw | 37 | 75 | 132 | ||
Spindle speed | r/min | 1480 | 1480 | 1480 | ||
Speed-adjustable motor | Model | - | YCT200-4A | YCT200-4B | YCT225-4A | |
Power | kw | 5.5 | 7.5 | 18.5 | ||
Spindle speed | r/min | 125~1250 | 125~1250 | 125~1250 | ||
Motor of elevator | Model | - | Y100L2-4 | Y100L2-4 | Y112M-4 | |
Power | kw | 3 | 3 | 4 | ||
Spindle speed | r/min | 1420 | 1420 | 1420 | ||
Motor of centrifugal induced draught fan | Model | - | Y225S-4 | Y280S-4 | Y315M1-4 | |
Power | kw | 37 | 75 | 132 | ||
Spindle speed | r/min | 1480 | 1480 | 1480 | ||
Motor of jaw crusher | Model | PE | 200x350 | 250x400 | 250x400 | 250x750 |
- | - | Y160M-6 | Y180L-6 | Y180L-6 | Y200L2-6 | |
Power | kw | 7.5 | 15 | 15 | 22 | |
Spindle speed | r/min | 970 | 970 | 970 | ||
Electromagnetic vibrating feeder | Model | - | GZ2F | GZ3F | GZ3F | |
Spindle speed | watt | 150 | 200 | 200 |
Shanghai Zenith Mining and Construction Mahicnery Co., Ltd. is an international and professional company, which engages in research & development, production and sale of the electric power equipment, powder making equipment such as vibration grinding mill , and mining equipment. Our products have been distributed to all the provinces in China as well as over 56 countries and regions in the world.We hold "Pursuing the Zenith Technology and Quality" as our management concept all the time. we have many different crushers and grinding stone mills for sale.
Packaging Detail:Standard Container |
Delivery Detail:30 days |
