Coffee Husk charcoal briquette making machine, 1.stick shape 50mm,70mm diameter, 2.raw like sawdust,shell, 3.moisture's 7-12 - details see: https://www.machineto.com/coffee-husk-charcoal-briquette-making-machine-supplier-10072726

coffee husk charcoal briquette making machine

Last the extruded wood briquette can be used as fuel for briquette boilers or boilers for heating.

Features:

1.Environmental protection

2.Automatic temperature control system,low energy consumption.

3.High wood briquettes density & capacity,

4.Long timecontinuous working-time per day

Flow chart

1. Crush the raw material into small pieces (diameter is about 3-5mm)
2. Dry the material by machine or dried it in the sun , till the moisture is less than 12%
3. Put the material into feed let of briquette machine
4. Produce the briquette stick from biomass material without any additive
5. Carbonized the briquette stick

Performace:

1. The motor: 11kw/15kw/18.5kw-3phase-380v-50hz electrical driven motor.

2.16 hourscontinuous working-time per day

3.The out final products diameter can be reached 50mm-70mm freely

4.It can be used as charcoal powder briquette machine by replacement of some spare parts.

Technical Data:

Machine Model	ZBJ-I	ZBJ-II	ZBJ-III
Capacity (KG/H)	150-200	200-300	350-400
Power (KW)	11	15	18.5
Electric Heater (KW)	3X1.5	3X1.5	3X2.2
Output Products Diameter (MM)	50	50-70	50-70
Machine Dimension (MM)	1660*745*1250	1700*800*1280	1920*630*1550
Weight (KG)	550	650	800

Raw materials:

Almost all type of Agro-Forestry waste can be used,including:

Groundnut-shell /Sugarcane residue Caster Shell/Stalk Saw dust/ Coffee Husk /Paddy Straw /Sunflower Stalk /Cotton Stalks/ Tobacco waste /Mustard Stalk /Jute waste

/Bamboo Dust /Tea waste /Wheat Straw /Palm husk /Soybeans husk/ Rice Husks/ Forestry wastes /Wood Chips etc

Finished product :

After the processing of drying, compressing under the high pressure and temperature, the biomass briquette is characterized by high density, small in size, better combustion, capable as the substitute for the superiorcoal or firewood. This bio-fuel briquette is 50-70mm in diameter, occurs in the hollow quadrangular or hexagonal cylier with a 15-20mm hole through the body.
