Chinese Herbal Grinder Machine 0086-15188300775
| Place of Origin:Henan China (Mainland) | Brand Name:AZS | Model Number:AZS-GM | Application:Powder |
| Type:grinder,grain/spice/herbs grinding machine | Material:304 stainless steel | Name:multi-function grinder machine | Grinding fineness:10-200mesh |
Chinese Herbal Grinder Machine
Details:
The Chinese Herbal Grinder Machineismade ofstainless steel,hassimple
structure,easy to operate.It can grindgrain/spice/Chinese herbs/chemical
materialsinto10-200Meshthrough changing sieves.
The grinding powder isfine and uniform.
It is suitable forpharmaceutical, chemical ,food industries and so on.
Workingprinciple:
1.Use the high speed between movable and fixed fluted disc to make the materials crushed by the tooth disc’impact, friction and collision.
2.Crushed material can directly get out from the grinding chamber to the discharging door, and then smashing into the collection bag.
3.Then the air comes out from the small hole of the bag without the fine powder, thusno waste and no pollution.
Parameters:
| Model | Capacity (Kg/h) | Fineness (Mesh) | Voltage (V) | Power (Kw) | Dimensions (mm) | Weight (Kg) |
| AZS-GM120 | 30-120 | 10-200 | 220/380 | 2.2 | 480*520*1040 | 80 |
| AZS-GM180 | 60-200 | 10-200 | 380 | 5.5 | 750*600*1260 | 180 |
| AZS-GM320 | 80-300 | 10-200 | 380 | 7.5 | 780*700*1350 | 260 |
| AZS-GM500 | 100-500 | 10-200 | 380 | 11 | 800*900*1550 | 320 |
Contact Person:Amy
Mobile:0086-151 8830 0775
Pictures of Chinese Herbal Grinder Machine:
Pictures of the production:
Contact Information:
| Packaging Detail:wooden case |
| Delivery Detail:7-10days after receipt of the deposit or L/C |
