Best ability alluvial gold wash plant

Gold Mining Equipment., 1. Gold Trommel: 300-500 t/h, 2. Roughing: Sluice Box, alluvial gold wash plant - details see: https://www.machineto.com/best-ability-alluvial-gold-wash-plant-10315737

Condition:New	Type:Gravity Separator	Production Capacity:96%	Place of Origin:Shandong China (Mainland)
Brand Name:alluvial gold wash plant	Model Number:HA01163	Voltage:110V-380V	Power(W):75 KW
Dimension(LWH):830024004200mm	Weight:15 ton	Warranty:1 year	After-sales Service Provided:Overseas service center available
Processing capacity:20-500 ton	Trommel Screen Size:1500*4500 mm	Trommel Screen Power:11 KW	Screen Material:20CrMo
Feeder hopper:300022001800 mm	Gold chutes with carpet:1000*6000 mm 3 sets	Water Pump:22 KW	Water flow:240 m3/h
Engine:50kw Diesel Engine	Water Head:22 m

contact supplier for Best ability alluvial gold wash plant

1. Gold Mining Equipment

	Weifang Heng An Imp&Exp Co., Ltd Parent Company: Weifang Heng An Radiator Group Co., Ltd (Founded in 1975) China Top Gold Mining Equipment Manufacturer For Gold Mining, Gold Washing, Gold Panning!

2. Mobile Gold Trommel

This Gold Trommel Wash Plant is easy to move, even if move it in Jungle.

The plant use gravity principle, whip and wash raw material in scrubber and trommel. It fixed all negative factor caused by high mud percent. The plant can be adjust in gold mine site, based on ore and field.

The machine is 4.7-5.2 meter high, need excavator to load material. The capacity is 300-500 ton per hour. Water consumption is 350-600 ton per hour.

Gold Wash Plant Working Process

Hopper—>Scrubber—>Washing Trommel—>Sluice or Concentrator—>Shaking Table—>Gold Furnace

Heng An Mobile Gold Trommel Wash Plant is a land removable gold mining equipment. It’s high integrated, unitary, easy control, big capacity, stable working, easy maintain, and easy moving.

Our engineer can go oversea to install our plant.

3. Small Gold Trommel

20-30 ton/h, 30-50 ton/h, 50-70 ton/h, 100-140 ton/h Gold Trommel Wash Plant.

Small Gold Trommel Wash Plant, Low Investment, High output.

We customized gold trommel wash plant for clients.

4. Roughing:Gold Sluice Box

Most alluvial gold mine are using Sluice for roughing. Fine gold are using gold concentrator.

Fixed Sluice

Fixed sluice are simple design, no need for power, big capacity, for coarse granule, big concentration ratio, easy maintain and easy use. But high strength work are for sluice cleaning. Fixed Sluice can do nothing for fine gold. Generally, fixed sluice gold recover rate is lower than 50%.

Fixed Sluice come with Gold Carpet.

Fluctuate Sluice

Due to high recover rate and low price, fluctuate sluice is more and more popular in gold mining market. More and more gold mining company disuse old fixed sluice, and buy fluctuate sluice.

Fluctuate sluice is easy and fast for cleanning. It only take 10-15 minutes to cleaning and recover gold sand, every 6 hours.

5. Concentrating:Gold Concentrator

Model	STL19	STL30	STL60	STL80	STL100
Capapcity T/H	0.25-0.30	3-5	15-20	40-50	80-100
Feed particles mm	0-3	0-4	0-6	0-6	0-6
Feed density %	0-50%	0-50%	0-50%	0-50%	0-50%
Recoil of water T/H	1.5-2	4-6	10-15	17-25	40-60
Concentrate production (kg per time)	2-3	10-20	30-40	60-70	70-80
Motor Power kw	0.75	3	7.5	11	18.5
Cone rotational speed	800	600	460	400	360
Water Pressure MPa	0.04	0.1	0.16	0.18	0.2
Overall Size mm	790×785×790	1150×1360×1250	1970×1670×1750	2300×1800×2200	2500×2000×2400
Weight	300kg	500kg	1300kg	1800kg	2800

STL Concentrator is a copy of Knelson Concentrator. It is not only used in placer gold mining, but also in hard rock mining to recover the natural gold, replacing amalgamation. It is also used to recover gold from the old tailings.

Our gold concentrator is a copy of Knelson Type concentrator. We have 5 models. Application shows that the recovery can be as high as 99%, especially for natural gold in lode ore with 65% milling size of 0.074mm, the recovery for the natural gold is expected up to 98%. For natural gold of 0.004mm in particle size, the recovery is 97%.

The cleaning up cycle is 1~4 hours. And the upgrade ratio is up to 1,000 times.

6.Gold Shaking Table

7.Gold Furnace
