1. CURTIS electronic control system, 2. Intelligent electronic instruments, 3. Ergonomic design, 4.long hours working battery. - details see: https://www.machineto.com/3-ton-electric-forklift-sf30s-ac-motor-10098536

STANDARD DIMENSIONS
General	Model		SF30S	unit
	Load capacity		3000	kg
	Load center		500	mm
	Power type		storage battery
Dimensions	Overall length(with fork/no fork)		3545/2470	mm
	Overall width		1295	mm
	Overall height		2135	mm
	Overall height fork lowered		2065	mm
	Overall height fork raised		4272	mm
	Max. lift size		3000	mm
	Free lift height		80	mm
	Min. ground clearance		140	mm
Wheel& base	Front overhang		495	mm
	Wheelbase		1585	mm
	rear overhang		392	mm
	Adjusting range of fork		250/1090	mm
	Front tread		1000	mm
	Rear tread		980	mm
Performance	Min. turning radius		2135	mm
	Mast tilit angle		6/12	o
	battery(voltage/capacity)		80/500	V/Ah
	Travel speed(full load/noload)		15/18	Km/h
	Lift speed with load		260	mm/sec
	Max. gradeality		13	%
	Weight of battery		1331	kg
	Tires	Front	28× 9-15-14PR
		Rear	18× 7-8-14PR
	Self-weight		4850	kg
