QPG type high lift winch hoist

Name: QPG type high lift winch hoist
SKU: 10097309

Model QPG Hoists Henan,China(Mainland) Ref 10097309

Price on request

Pricing is provided on request — use the quote form below.

Port: Tianjin/Qingdao/Shanghai/Other
Minimum Order Quantity: 1 Set/Sets
Supply Ability: 250 Set/Sets per Month
Payment Terms: L/C,T/T,Western Union

Something wrong with this listing? Report it

Key features

QPG type high lift winch hoist·1.CE, ISO, SGS, GOST passed·2.One year warranty·3.Senior engineer's technical support

Specifications

Condition	New	Place of Origin	Henan China (Mainland)
Model Number	QPG	Usage	Other
Power Source	Electric	Sling Type	Wire Rope
Maximum Lifting Weight	2.5T	Maximum Lifting Height	20m
Lift Speed	1.10~2.57m/min	Certification	CE, ISO, GOST, SGS
Warranty	1 year for main body	After-sales Service Provided	Engineers available to service machinery overseas
Details	QPG type high lift winch hoist · 1.CE, ISO, SGS, GOST passed · 2.One year warranty · 3.Senior engineer's technical support

Packaging & delivery

Packaging Detail	QPG type high lift winch hoist: packed with wooden case.
Delivery Detail	10 working days after advanced payment received.

Product description

Description of QPG type high lift winch hoist

We have passed ISO9001:2000 quality system certification, and gained State Administration of Quality Supervision, Inspection and Quarantine issued by the construction hoist production license.
Main products: JK (fast), JM, JMW (slow), JT (governor), JKL, 2JKL rapid series of manual and electric winch and hoist of all kinds of non-standard production. Our products are widely used in mining, metallurgical, lifting, construction, chemical, road and bridge, water and electricity installed, the terminal, oil and other industries.
With perfect tooling, strong technical force, a sound management system and advanced detection equipment, our product quality is stable and reliable.

Productive process

Packing

Application

Technical parameters of QPG type high lift winch hoist

Classification		Model	Gate opening force (KN)	Height (m)	Speed (m/min)	Motor
Classification		Model	Gate opening force (KN)	Height (m)	Speed (m/min)	Model	Power(KW)
Single hanging point	Separate drive	QPG-50	50	8-20	1.47	Y112M-6	2.2
		QPG-80	80	10-20	2.20	Y132M-6	4
		QPG-100	100	10-20	2.20	Y132M-6	4
		QPG-125	125	11-20	2.57	Y132M-6	5.5
		QPG-160	160	11-20	2.57	Y132M-6	5.5
		QPG-250	250	12-20	2.44	Y160M-6	7.5
		QPG-400	400	13-20	1.95	Y160L-6	11
		QPG-630	630	13-20	1.10	Y180M-6	15
		QPG-800	800	13-20	1.47	Y225M-6	22
		QPG-1000	1000	10-20	1.25	YZR250M-8	26
		QPG-1250	1250	10-20	1.19	YZR250M-6	35
Double hanging point	Centralized driving	QPG-2×50	2×50	8-20	1.47	Y132M-6	4
		QPG-2×80	2×80	10-20	2.20	Y132M-6	5.5
		QPG-2×100	2×100	10-20	2.20	Y160M-6	7.5
		QPG-2×125	2×125	11-20	2.57	Y160M-6	7.5
		QPG-2×160	2×160	11-20	2.57	Y160M-6	11
		QPG-2×250	2×250	12-20	2.44	Y180M-8	11
		QPG-2×400	2×400	13-20	1.95	Y225M-6	22
	Separate drive	QPG-2×630	2×630	13-20	1.50	Y180M-8	2×15
		QPG-2×800	2×800	13-20	1.47	Y225M-6	2×22
		QPG-2×1000	2×1000	10-20	1.25	YZ225M-8	2×26
		QPG-2×1250	2×1250	10-20	1.19	YZ225M-8	2×35

About us

Ordering instructions

The basic parameters (rated lifting weight, lifting height ,working environment and other special requirement, etc.) of QPG type high lift winch hoist shall be described clearly when the user orders goods or signs a contract so that the product which may satisfy the working condition can be supplied.Welcome to contact us by phone or e-mail!
