MR-144C sawtooth cottonseed delinting machine
Price on request
Pricing is provided on request — use the quote form below.
- Port
- Qingdao
- Minimum Order Quantity
- 4 Set/Sets
- Supply Ability
- 800 Set/Sets per Year
- Payment Terms
- L/C,T/T
Price on request
Pricing is provided on request — use the quote form below.
Something wrong with this listing? Report it
MR-144C sawtooth cottonseed delinting machine:·1. low power consumption·2. high quality·3. high output·4. save money
| Place of Origin | Shandong China (Mainland) | Model Number | MR-144C sawtooth linter |
|---|---|---|---|
| delinting machine | MR-144C sawtooth cottonseed delinting machine | award | national patent |
| saw blade | 144pcs | Overall dimension | 2500*1800*1900(mm) |
| Power equipped | 24.35 KW | condition | new |
| Details | MR-144C sawtooth cottonseed delinting machine: · 1. low power consumption · 2. high quality · 3. high output · 4. save money |
| Packaging Detail | standard export packing |
|---|---|
| Delivery Detail | 3 weeks after down payment |
MR-144C sawtooth cottonseed delinting machine
MR-144C sawtooth cottonseed delinting machine:
1. low power consumption
2. high quality
3. high output
4. save money
1. MR-144C sawtooth cottonseed delinting machine is used to strip the lint from gross cotton seed.
2. We adopt new technology, new process and new material to make the work property improve effectively, especially highlight its obvious advantages for the auto control cabinet and production efficiency .
3. MR-144C sawtooth cottonseed delinting machine can be divided into three specifications separately used to strip the 1st, 2nd and 3rd cut lint; the 2nd and 3rd belong to air-flow type.
4. MR-144C sawtooth cottonseed delinting machine can be used as matching equipment with other cotton ginning machine ( the match ratio depends on the actual requirements)
1. Main technical parameters | MR-144C sawtooth cottonseed delinting machine |
| Process capacity (kg/h) | |
| The first process capacity | 3500-4500 |
| The second process capacity | 1000-1500 |
| The third process capacity | 750-1000 |
| Lint output ratio (%) | |
| The first lint output ratio | 1-1.5 |
| The second lint output ratio | 4-6 |
| The third lint output ratio | 2.5-3.5 |
| Short-time lint output (kg) | |
| The first short-time lint output | 0.29 |
| The second short-time lint output | 0.35 |
| The third short-time lint output | 0.21 |
2. Main technical parameters | MR-144C sawtooth cottonseed delinting machine |
| Roller of saw-blade | (φ280-φ320)×1588.73(mm) |
The first of the tooth-shape angle of saw blade is40°, the second and the third is 28°( tooth height 5-5.5mm) | |
| Saw-blade number | 144 pcs |
| Saw-blade interval | 11.11mm |
| Max. frame inclination | 28-30° |
| Discharge-strip clearance | 2.8-3(mm) |
| Blowing-rate at lint outlet | 1.5-1.6 m3/s(non-load) |
| Wind-speed at lint outlet | 19-20 m/s(non-load) |
| Power equipped | 24.35 KW |
| Overall dimension | 2500×1800×1900(mm) |
| Weight | 2t |
3. Motor model for MR-144C sawtooth cottonseed delinting machine:
Y160L-4 15KW Y132M-4 7.5KW
Y90S-4 1.1KW Y80M2-4 0.75KW
Raw material(ginned cottonseed) → MR-144C sawtooth cottonseed delinting machine→ delinted cottonseed
