metal lathe

Belt driving hobby lathe;V-way bed is hardened and precision ground. Super width bedway gets greater capacity etc. - details see: https://www.machineto.com/metal-lathe-10127878

Condition:New	Type:Horizontal	CNC or Not:Normal	Place of Origin:China (Mainland)
Brand Name:KY	Model Number:KY250M

SPECIFICATION:
Model No.	KY250M
Distance between centers	550 / 750mm
Swing over bed	250mm
Swing over cross slide	150mm
Width of bed	135mm
Taper of spindle bore	MT4
Spindle bore	26mm
Number of spindle speeds	6
Range of spindle speeds	125-2000rpm
Range of longitudinal feeds	0.07-0.20mm/r
Range of inch threads	8-56T.P.I
Range of metric threads	0.4-3.5mm
Top Slide travel	70mm
Cross slide travel	115mm
Tailstock quill travel	70mm
Taper of tailstock quill	MT2
Motor	750W
Net weight	120/140kg
