metal lathe

Economical, widely useful hobby lathe;V-way bed is precision ground; Gear head enables to quickly change speeds etc. - details see: https://www.machineto.com/metal-lathe-10127736

Condition:New	Type:Horizontal	CNC or Not:Normal	Place of Origin:China (Mainland)
Brand Name:KY	Model Number:KY250B

SPECIFICATION:
Model No.	KY250B
Max. Swing Over Bed	250mm
Distance between centers	500mm
Max. Swing over cross slide	100mm
Spindle bore	26mm
Taper of Spindle bore	MT4
Steps of Spindle Speeds	12
Range of Spindle speeds	80-1600r/min
Cross slide travel	130mm
Top slide travel	60mm
Range of metric threads	15/ 0.25 -2.5mm
Range of Inch threads	9/12-96 T.P.I.
Range of Longitudinal feed	0.03 -0.275mm/r
Range of Cross feed	0.015-0.137mm/r
Max. travel of Tailstock Sleeve	MT3
Motor	750W 400V 50Hz(110V60Hz)
Net Weight	135Kg
Packing size (L×W×H)	260×640×580mm
