Manual Positioning Stage , Linear Motion Stage
Price on request
Pricing is provided on request — use the quote form below.
- Port
- TAIWAN
- Minimum Order Quantity
- 1 Piece/Pieces
- Payment Terms
- T/T
Price on request
Pricing is provided on request — use the quote form below.
Something wrong with this listing? Report it
Positioning Linear Motion Stage - XY axes·1.Mechanism: linear ball·2.Travel stroke: +/- 3.2mm·3.Straightness accuracy: 3um
| Place of Origin | Taiwan | Model Number | MY40-SS |
|---|---|---|---|
| Details | Positioning Linear Motion Stage - XY axes · 1.Mechanism: linear ball · 2.Travel stroke: +/- 3.2mm · 3.Straightness accuracy: 3um |
| Packaging Detail | Standard export carton. Paper pallets. |
|---|---|
| Delivery Detail | By order |
:: GMT Linear Motion System :: Linear Motion Stage :: Mini Stage - Linear Ball Bearing / XY axes
GMT Mini Stage with high accuracy level creates high positionoing performances.
It is applied for high precision or mid and heavy capacity of various testing devices,
precise positioning and quantitative movement.
* Product Specification:
| Model No. | Table Size | Axis | Axis feed position | Travel stroke | Movemenet accuracy straightness | Load capacity (kgf) | Weight (kg) | Material | Surface finish | Minimum reading |
| MY40-SS | 40mm*40mm | XY | Side | ±6.5 mm | 3 µm | 9.7 | 0.46 | Stainless Steel | Nickel Plating | 10 µm |
* Product Pictures:
* Applications:
This applied to precise positioning device in high accuracy and mid- capacity, such as:
- Prosuction and design integration system, Conformity system ;
- Optical experiment ; Precise translation instruments ; Fine tuning mechanism application , etc.
* Overseas exhibitions:
* Factory view:
* ISO Certification:
