furnace for glass mosaic

1) used 6 to 10(mm) slab glass, 2)monthly production : 12000 to 15000 square meters, 3) PID intelligent temperature control - details see: https://www.machineto.com/furnace-for-glass-mosaic-10085238
Condition:NewPlace of Origin:Jiangsu China (Mainland)Brand Name:YYTModel Number:YYT-SJTT
After-sales Service Provided:Engineers available to service machinery overseasMaximal use temperature:1000℃temperature control point:5 pics
furnace for glass mosaic
contact supplier for furnace for glass mosaic


Technical parameters:

1. Furnace effective size: L36000×B1200×H100(mm);

Furnace configuration size: L36000×B2400×H1200(mm);

2. Maximal use temperature: 1000°C;

3. temperature control point:5 pics;

4. Temperature-control accuracy: ±1°C;

5. Electrothermal element: electrothermal alloy wire;

6. Electrical heating power:250KW/380V(three-phase);

7. Average insulation power: 180Kw/380v/h;

8. Temperature control method: PID PC intelligent digital display temperature control, SCR silicon module control imported from Germany, temperature control device configuration manual, linear proportional output, manual and automatic regulation, adjustable power, automatic constant temperature, fault alarm;

9. Transmission mode: bevel gear ceramic roller;

10. Roller specification: φ45mm high-aluminum ceramic roller;

11. Feeding style: continuous feeding;

12. Roller speed control: 2 groups of frequency control, roller speed adjustable;

13. Total weight: about 30 tons.

furnace for glass mosaic
Packaging Detail:Export package or according the customer requirement
Delivery Detail:40 days after received the payment
