bottle packing machine

Name: bottle packing machine
SKU: 10065281

Model YCBS80 Wrapping Machines Beijing,China(Mainland) Ref 10065281

Price on request

Pricing is provided on request — use the quote form below.

Something wrong with this listing? Report it

Key features

1. manufacture·2. bottle packing line·3. ued for beer,beverage,pure water,fruit juice,etc·4.CE certification·5. middle speed

Type	Wrapping Machine,YCBS80	Condition	New
Application	Beverage	Packaging Type	Cartons,Cans,Bottles,Film
Packaging Material	Plastic,LDPE	Automatic Grade	Automatic
Driven Type	Mechanical	Voltage	380V
Power	55KW	Place of Origin	Beijing China (Mainland)
Model Number	YCBS80	Dimension(LWH)	1814515302500
Weight	4600kg	Certification	ISO9001
After-sales Service Provided	Engineers available to service machinery overseas	name	bottle packing machine
operate way	touch screen	packing speed	70-80 packs/min
Usage	bottled water	rollers	signle roller
packing film	print film and common film	manufacture	yes
life span	long	national patent technology	ISO9001
Details	1. manufacture · 2. bottle packing line · 3. ued for beer,beverage,pure water,fruit juice,etc · 4.CE certification · 5. middle speed

Packaging Detail	WOODEN CARTON PACKING, 35CBM
Delivery Detail	30 days

bottle packing machine
Specially designed for the full automatic packaging production line of beer, beverage,purewater,fruit juice,dairy products,etc.
With full automatic functions of bottle transfer and arrange, membrane packing ,sealing and cut,shrinkage,cooling and shaping,etc.
Using advanced constant temperature membrane heat binding technology in the world with clear and secure seal.
The quick seal cooling structure guarantee that the seal has a higher strength even if under high speed production condition.
Adopt with PLC automatic program circulation control with stable and reliable performance.
The original imported guide bar cylinder guarantee correct op[eration and durable.
The inductive switch controls the membrane transfer system to reliably adjust and control the membrane transfer length with less loss.
All the transfer system is controlled by frequency changing devices With stable and smooth transfer speed.
Unique thermal passage with 2 sets of centrifugal thermal air circulation system that has an equal heat distribution with beautiful and secure shrinkage effect.
3 layers of heat insulation treatment with good insulating property,quick temperature rise and energy saving.
The enhanced cooling shaping passage can quickly turn the packaging membrane into high strength status that is conveniently stored and transported.
It is easy to change the packaging combination and bottle type to integrate the multi-function into one machine.

liquid packing machine SPECIFICATION:

Dimension for the whole unit:	L18145mm×W1530mm×H2500mm
Thermal shrinkage passage dimension:	L3000mm×W700mm×H450mm
Max.package dimension:	L460mm×W280mm×H350mm
Transfer belt width:	610mm
Packaging speed:	70-80 Pcs/min
Operating power supply/power:	380v 55kw
Sealing and cut time/temperature:	0.5-1.5s140oC-160oC
Operating air pressure:	0.6-0.8Mpa
Air consumption:	0.5m3/minute
