5 Gallon washing filling caping machine
Price on request
Pricing is provided on request — use the quote form below.
- Port
- ningbo
- Minimum Order Quantity
- 1 Unit/Units
- Supply Ability
- 20 Unit/Units per Month
- Payment Terms
- T/T
Price on request
Pricing is provided on request — use the quote form below.
Something wrong with this listing? Report it
washing filling caping machine1, Produce water2, Easy to control3, Normal temperature, normal pressure
| Place of Origin | Zhejiang China (Mainland) | Model Number | QGF-120 |
|---|---|---|---|
| Details | washing filling caping machine1, Produce water2, Easy to control3, Normal temperature, normal pressure |
| Packaging Detail | wooden pakage |
|---|---|
| Delivery Detail | 30 days |
QGF automatic jar water production is specialized for 5 gallon bottle water producing. The whole line include washing machine, filling machine and capping machine. It is ideal equipment for producing mineral water and pure water. The all machines are mainly made of SUS304 stainless steel. The main electric components are chosen from international famous brand, such as OMRON, MITSUBISHI and so on and air channel system are chosen from Taiwan AirTAC brand. The machine structure is compact and takes up little space, high efficiency and stabilization.
Main technical parameter:
ModelQGF-120
Filling Nozzle: 1 Nozzle
Bottle loader (filling line): 1 Row
Overall size3200 x 1400(1000) x 1600 (L type)
Production capacity: 120B/H
Voltage380V50Hz, max consumption 2KW.
Washing procedure
The first and second proceduredisinfectant washingthird and fourth procedurecycle waterfifth and sixth procedure: Purified waterthe seventh procedure: Drying; The eighth proceduredown-loading bottle
Gas pressure 0.5~0.6MP, gas consumption: 0.3m3; /h
Intelligentize manager OMRON PLC control
| Model | QGF-120 | QGF-300 | QGF-450 | QGF-600 | QGF-900 | QGF-1200 | |
| Filling heads | 1 | 2 | 3 | 4 | 6 | 8 | |
| Volume | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | |
| Barrel size | Φ 270*490 | Φ 270*490 | Φ 270*490 | Φ 270*490 | Φ 270*490 | Φ 270*490 | |
| Capacity | 120 | 300 | 450 | 600 | 900 | 1200 | |
| Gas pressure | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.6 | 0.6 | |
| Gas consumption | 0.37 | 0.37 | 0.6 | 0.8 | 1 | 1.5 | |
| Moto power | 1.38 | 1.75 | 3.8 | 3.8 | 7.5 | 9.75 | |
| Rated voltage | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ |
